Ametek MX45-3Pi - Page 247

User Manual – Rev BE AMETEK Programmable Power
MX Series 247
Re f.
CI P / N
Description
Ve n d o r
Qt y
Lo c a t i o n
Am p l i f i e r As s y. 15kVA 7003-418-1
A1 7003-704-1
PC Assy., Modulator AMETEK P P
1 A7 , A8 , A9
Q1 330436
Transistor, IGBT IXYS, IXGX60N60C2D1
4 A7 , A8 , A9
Q2 330436
Transistor, IGBT IXYS, IXGX60N60C2D1
4 A7 , A8 , A9
Q3 330436
Transistor, IGBT I XYS , IXGX60N60C2D1
4 A7 , A8 , A9
Q4 330436
Transistor, IGBT IXYS, IXGX60N60C2D1
4 A7 , A8 , A9
Amplifier Assy. 15kVA 7003-425-1 / 7003-425-2
A1 7003-720-1
PC Assy., Modulator (-1) AMETEK PP
1 A7 , A8 , A9
A1 7003-724-1
PC Assy., Modulator (-2) AMETEK PP
1 A7 , A8 , A9
Q1 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q2 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q3 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q4 330450
Transistor, FET I NFI NEON, IPW60R045CPXK
4 A7 , A8 , A9
Am p l i f i e r As s y. 1 5 k VA - 7003-418-1 / 7003-425-1 / 7003-425-2
A3 7003-405-1
Heat sink Assy. Amplifier AMETEK PP
1 A7 , A8 , A9
A4 7003-405-1
Heat sink Assy. Amplifier AMETEK PP
1 A7 , A8 , A9
A5 7003-707-1
PC Assy., Output Filt e r AMETEK P P
1 A7 , A8 , A9
A6 7003-707-2
PC Assy., Output Filter AMETEK P P
1 A7 , A8 , A9
A7 7003-716-1
PC Assy., PFC AMETEK P P
1 A7 , A8 , A9
A8 7003-708-1
P C As s y. , Fa n Co n t r o l AMETEK P P
1 A7 , A8 , A9
A8 7003-717-1
PC Assy., Snubber. (-1) AMETEK PP
1 A7 , A8 , A9
A8 7003-725-1
PC Assy., Snubber. (-2) AMETEK PP
1 A7 , A8 , A9
B1 241183
FAN, 6 " ROTRON J Q2 4 B2
1 A7 , A8 , A9
B2 241183
FAN, 6 " ROTRON J Q2 4 B2
1 A7 , A8 , A9
Amplifier Assy. 15kVA 7003-433-2 / 7003-433-5
A1 7003-727-1
PC Assy., Modulator (-1) AMETEK PP
1 A7 , A8 , A9
7003-727-5
PC Assy., Modulator (-5) –SNK AMETEK P P
1 A7 , A8 , A9
A5 7003-726-1
PC Assy., Output Filter AMETEK P P
1 A7 , A8 , A9
A6 7003-726-2
PC Assy., Output Filter AMETEK P P
1 A7 , A8 , A9
Q1 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q2 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q3 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
Q4 330450
Transistor, FET INFINEON, IPW60R045CPXK
4 A7 , A8 , A9
CR1 3 310387
Dio d e , FRcy, 30A, 1000V APT, APT30D100B
1
CR1 4 310387
Diode, FRcy, 30A, 1000V APT, APT30D100B
1
CR1 5 310387
Diode, FRcy, 30A, 1000V APT, APT30D100B
1
CR1 6 310387
Diode, FRcy, 30A, 1000V APT, APT30D100B
1
Q1 330437
Transistor, IGBT FUJ I , 2MBI150NC-060
1 A7 -PFC
Q2 330437
Transistor, IGBT FUJI, 2MBI150NC-060
1 A8 -PFC
Q3 330437
Transistor, IGBT FUJI, 2MBI150NC-060
1 A9 -PFC
Am p l i f i e r As s y. 1 5 k VA - 5440224-01
A1 5440217-01
P WA , MODULATOR -MX AMETEK P P
1 A7 , A8 , A9
A5 5440218-01
P WA , OUP UT FI LTER -MX AMETEK P P
1 A7 , A8 , A9
