User Manual – Rev BE AMETEK Programmable Power

MX Series 87

To set up a GPIB remote-controlled clock and lock systems, the GPIB addresses

for the individual MX's must be set to different address values in the UTILITY1,

GPIB/RS232 SETUP screen.

NOTE: This mode of operation is not supported by the VIRTUAL

PANELS Windows software supplied with each MX unit.
