Chapter 5. Installation/Commissioning Procedure
5
In addition to the XML file, you may save a report file that is more readable. A sample is provided here:
Software Revision: 4.01
Unit IP: 10.14.3.52
MAC Address: 00:07:5E:00:20:1C
Catalog Number: US1NEM9AFSX
Date/Time: Fri Sep 19 14:30:30 2014
System ID (Major): Substation X
System ID (Minor): Line Y
General Settings
Channel Type: FSK
Function : 3-Frequency
Rear Ethernet Mode: Redundant
Transmit Frequency: 250.00 kHz
Receive Frequency: 252.00 kHz
TX Shift-Bandwidth: 600 ± 250
RX Shift-Bandwidth: 600 ± 250
RF coax connection: 4 Wire
RF Impedance: 50 Ohms
Transmit Power Low: 1.0 W
Transmit Power High: 10.0 W
RX Sensitivity: 118.1 mV
Fade Alarm: 10 dB
Fade Margin: 15 dB
Reflected Power Alarm: 15 %
Transmitter: Enabled
Receiver: Enabled
Current margin: 15.0 dB
Current receive level: 9 dB
Current transmit power: 30 dBm
Current reflected power: 0.0%
Session Time Out: 30 Min.
Logic Settings
CB Trip Test: Enabled
Line Relay Settings
Pre-Trip Delay: 4 ms
Trip Hold: 0 ms
Guard Hold: 0 ms
Unblock Timer: 150 ms
Unblock Delay: 10 ms
Guard Before Trip: Required
Direct Transfer Trip Settings
Pre-Trip Delay: 30 ms
Trip Hold: 0 ms
Guard Hold: 0 ms
Guard Before Trip: Required
Input Output Settings
Inputs
1. Hold: 0.0 ms
Selection: LR Key
Active State: Application of Voltage
Voltage: 125
2. Hold: 0.0 ms
Selection: DTT Key
Active State: Application of Voltage
Voltage: 125
3. Hold: 0.0 ms
Selection: Power Off
Active State: Application of Voltage
Voltage: 125
4. Hold: 0.0 ms
Selection: Trip Test
Active State: Application of Voltage
Voltage: 125
5. Hold: 0.0 ms
Selection: SOE Event 1
Active State: Application of Voltage
Voltage: 125
Trip Duty Outputs
1. Selection: LR Guard NC Contact
2. Selection: LR Trip NC Contact
3. Selection: DTT Guard NC Contact
4. Selection: DTT Trip NC Contact
Power Supply Alarms Contacts
Main Power Supply Normally Closed
Redundant Power Supply: Not Installed
Low Level Outputs
1. Selection: LR Guard
De-energized State: NO
Action: Normal
Max Load: 1.0A
2. Selection: LR Trip
De-energized State: NO
Action: Normal
Max Load: 1.0A
3. Selection: DTT Guard
De-energized State: NO
Action: Normal
Max Load: 1.0A
4. Selection: DTT Trip
De-energized State: NO
Action: Normal
Max Load: 1.0A
5. Selection: Fade Alarm
De-energized State: NO
Action: Normal
Max Load: 1.0A
6. Selection: Good Channel
De-energized State: NO
Action: Normal
Max Load: 1.0A
7. Selection: TX Shift Low
De-energized State: NO
Action: Normal
Max Load: 1.0A
8. Selection: Reflected Power
De-energized State: NO
Action: Normal
9. Selection: Main RF Output
De-energized State: NO
Action: Normal
10. Selection: General Alarm
De-energized State: NC
Action: Normal
Trip Test Settings
Auto Test: On
Trip Test Type: CB Trip
Trip Test Type: Periodic
Trip Test Hours: 6:00
Trip Test Hours: 12:00
Trip Test Hours: 18:00
Trip Test Hours: 0:00
Trip Test Period: 72
Options
Configuration: Single Transceiver
Power Supply: 110/125/250 Vdc
Redn. Power Supply: None
Outputs: Standard Outputs w/ Trip Duty
Logic: Standard
Ethernet Ports (Rear): Redundant/Daisy
Chain 2 RJ-
45(10/100 BaseT)
Protocols: DNP 3.0
Front Port: Ethernet / RS-232
Testing: ON-OFF CB Test / FSK Trip Test
Power Amp Features: Improved Power Amp w/
Freq Selectivity for Refl Power
