Page #11 background image
January 2016 Page 1–3
Chapter 1. Ordering Information
1
UPLC-II™ Catalog Number Digits Explanation
Digit and Description
1. Always starts with letter U
2. Configuration
Transceiver or Receiver only (RX only eliminates the Power Amp module)
Single or dual (redundant) Power Amps
3. Main Power Supply Type (Input voltage and auxiliary Power Supply)
48Vdc
110/125/250 Vdc (also runs off 120Vac)
With or without Aux. PS module to drive older EM relays with 20/200mA (Aux output is on
TB1/TB2 for putting in series with an output to get the correct current.)
4. Redundant Power Supply – Yes or No
5. Outputs (with or without 4 optional Trip Test Duty relay outputs) Yes or No
– Yes or No / Special Logic (FSK 4-Frequency)
(This digit specifies 2 different features with one digit)
6. Ethernet Interface Options (Rear Port Connectors)
Dual Electrical RJ-45
Dual Fiber ST
One Electrical, RJ-45/One Fiber, ST
7. Communications Protocol options
None, DNP3 or IEC61850
8. Testing Facilities – Yes or No
ON/OFF mode = Checkback Test
FSK mode = Trip Test (Shift from guard to trip in test mode without real trip output)
9. Power Amp options
None, Receiver-only unit
Power Amp with Freq. Selectivity for TX Reflected power meter
10. Future place holder
11. Future place holder
(All UPLC-II™ Catalog numbers end in “SX”)
