January 2016 Page 5–19
Chapter 5. Installation/Commissioning Procedure
5
Selection Steps
Function Directional or Phase Comparison N/A
TX Frequency 30 to 535 kHz 10 Hz
RX Frequency 30 to 535 kHz 10 Hz
Bandwidth 600, 1200 or 4,000 Hz N/A
TX Power* Low Power / High Power (0.3 to 10 W) 0.1 W
(RX) Fade Alarm 1 to 25 dB 1 dB
(RX) Fade Margin 1 to 25 dB 1 dB
Table 5–4. General Settings
(ON/OFF Mode)
Selection Steps
Function Phase Comparison, Unblocking-2F N/A
POTT/DTT-2, 3 or 4 Frequency
TX Frequency 30 to 535 kHz 10 Hz
RX Frequency 30 to 535 kHz 10 Hz
Bandwidth 300, 600 or 1,200 Hz N/A
Shift 100, 250 or 500 Hz N/A
TX Power* Low Power (Guard Freq.) / 0.1 W
High Power (Trip Freq.) - (0.3 to 10 W)
(RX) Fade Alarm 1 to 25 dB 1 dB
(RX) Fade Margin 1 to 25 dB 1 dB
Table 5–5. General Settings
(FSK Mode)
* For units with a redundant Power Amp module, the TX power is for only one Power Amp.
So for a 1W/10W setting the total TX power is twice this setting or 2W/20W.
