Appendix E: Sequence Of Events (SOE)Listing
E
January 2016 Page E–5
Transmitter Functions
Trip key
Trip key reset
3-Frequency Mode
Receiver Functions
DTT checkback trip
DTT checkback trip reset
DTT guard
Loss of DTT guard
DTT trip
DTT trip reset
LR checkback trip on
LR checkback trip reset
LR guard
Loss of LR guard
LR trip
LR trip reset
Transmitter Functions
LR trip key
LR trip key reset
DTT trip key
DTT trip key reset
Phase Comparison
Receiver Functions
Trip negative off
Trip negative on
Trip positive off
Trip positive on
Transmitter Functions
PC Key Off
PC key on
Trip Test Events
Failed Trip Test
Passed Trip Test
Received CB Trip Test request
Received real Trip Test request
Request CB Trip Test
Request real Trip Test
4-Frequency Mode
Receiver Functions
Checkback Trip A
Checkback Trip A Reset
Trip A
Trip A Reset
Loss of Guard A
Guard A
Loss of Guard B
Guard B
Checkback Trip B
Checkback Trip B Reset
Unblock A
Unblock A Reset
Unblock B
Unblock B Reset
Both Trip A & B
Both Trip A & B Reset
Guard A & B
Guard A & B Reset
Checkback Trip A & B
Checkback Trip A & B Reset
Transmitter Functions
A key
B key
A & B key
