January 2016 Page 3–15
Chapter 3. Applications
3
Transmit Monitor for ON/OFF Units Only
Output Reason: TX signal level is ≥ TX low level setting
Output Name: Main RF Output (LL01 – LL10)
(Available Outputs)
De-energized State
Output Type: N.O. Output N.C. Output
UPLC-II™ Condition
Transmit ON Closed Open
Transmit OFF Open Closed
TX / RX Alarms for ON/OFF Units with Checkback (CB) Option Only
Alarm Reason: UPLC-II™ failed all checkback UPLC-II™ failed all checkback
tests performed tests performed
at the 10 W level at the 1 W level
Alarm Name: Checkback Major Alarm Checkback Minor Alarm
(Available Outputs) (LL01 – LL10) (LL01 – LL10)
De-energized State De-energized State
Output Type: N.O. Output N.C. Output N.O. Output N.C. Output
UPLC-II™ Condition
Passed CB Test Open Closed Open Closed
Failed CB Test Closed Open Closed Open
Table 3–3 Continued:
Software Programmable Alarms/(Outputs from I/O Board)
ON/OFF Mode
* If a UPLC-II™ has both Major & Minor Checkback alarms, then that unit is faulty and needs to be checked.
