AMX NXD-1200V

Firmware Pages and Descriptions
93
NXD/T-1200V Wall/Flush Mount Touch Panel
Protected Setup Page Elements (Cont.)
System Recovery: Allows you to either reset the touch panel to factory default settings and/or wipe out all existing
touch panel pages:
• The Reset System Settings button allows a user to wipe out all current configuration
parameters on the touch panel (such as IP Addresses, Device Number assignments,
Passwords, and other presets).
- Pressing this button launches a Confirmation dialog (FIG. 93) which asks you to confirm
your selection.
- This dialog is configured with a delay timer that does not enable the YES button for 5
seconds. This delay provides an additional amount of time for the user to confirm their
decision.
• The Remove User Pages button allows you remove all current TPD4 touch panel pages
currently on the panel (including the pre-installed AMX Demo pages).
- Pressing this button launches a Confirmation dialog (FIG. 93) which asks you to confirm
your selection.
- This dialog is configured with a delay timer that does not enable the YES button for 5
seconds. This delay provides an additional amount of time for the user to confirm their
decision.
Keyboard Layout:
(build 2.60 or higher)
Displays the listing of supported international keyboard settings. The following list allows the
end-user to specify which international keyboard is being connected to the Modero touch panel
and then which characters should be reflected within the G4 Computer Control and TakeNote
applications:
- None (default), Spanish, Italian, French, German, Swiss, UK, and US
Note: You must be using a standard 101 button keyboard to accurately
utilize this feature.
• Modero uses the open-source VNC character standards to transmit the character
information to a target device such as a PC.
• One of the issues which occurred in the past was that some 101-key foreign keyboard
character sets were being incorrectly represented via the Computer Control and Take
Note applications.
• For example: Spanish keyboards consisting of Castilian character sets such as tilde (
é)
were being miscommunicated by the VNC application to the source computer and as a
result, passwords were not properly being entered.
• The VNC - Computer Control keyboard drivers found in earlier Modero firmware (build 57
or earlier) were using an English type/character set which was not fully utilizing all
available foreign characters.
• Several different countries have produced 101-key international keyboards, each with
their own unique set of keys occupying the keyboard. Several of these keys are specific to
the language they are used with.
FIG. 93
Protected Setup page-System Recovery confirmation dialog
You have a wait time of 5 seconds
before the YES option is enabled.
