AMX NXD-1200V

Programming
131
NXD/T-1200V Wall/Flush Mount Touch Panel
"^" Button Commands (Cont.)
^SKT Receive touch information on specified socket.
Syntax:
'^SKT-<0=disable socket, greater than 1023=enable socket on specified port>
Only socket values equal to or greater than 1024 are valid. The panel will open up a TCP listening socket
on the port specified. User or 3rd party program can connect to the panel using this port/socket number
and receive touch/release/move strings. By default, the panel disables touch notifications on startup.
Format of the output is:
<Press/Release/Move>,<x-coordinate>,<y-coordinate>
Example:
send_command TP, '^SKT-7425' (enables touch notifications on socket 7425)
send_command TP, '^SKT-0' (disable touch notification)
^TEC Set the text effect color for the specified addresses/states to the specified color. The Text Effect is
specified by name and can be found in TPD4. You can also assign the color by name or RGB value
(RRGGBB or RRGGBBAA).
Syntax:
"'^TEC-<vt addr range>,<button states range>,<color value>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
color value = Refer to theRGB Values for all 88 Basic Colors table on page 110.
Example:
SEND_COMMAND Panel,"'^TEC-500.504&510.515,1&2,12'"
Sets the text effect color to Very Light Yellow on buttons with variable text 500-504
and 510-515.
^TEF Set the text effect. The Text Effect is specified by name and can be found in TPD4.
Syntax:
"'^TEF-<vt addr range>,<button states range>,<text effect name>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
text effect name = Refer to theText Effects table on page 133 for a listing of text effect names.
Example:
SEND_COMMAND Panel,"'^TEF-500.504&510.515,1&2,Soft Drop Shadow 3'"
Sets the text effect to Soft Drop Shadow 3 for the button with variable text range 500-504 and 510-515.
^TOP Enables/disables touch output to Master If enabled, Press/Move/Release events are sent to the Master
as string events.
Syntax:
"'^TOP-<state>'"
<state> is 0(disable) 1(presses/releases), 2(moves), 3(press/move/release).
Note: Move should be used with caution. This setting can generate a significant amount of traffic to the
master depending on user interaction.
Example command: "'^TOP-1'"
Example Response: "String Event: Text: Press,320,480"
Example Response: "String Event: Text: Release,320,480"
