NXD/T-1200V Wall/Flush Mount Touch Panel
Programming
Overview
You can program the touch panel, using the commands in this section, to perform a wide variety of operations using
Send_Commands and variable text commands.
A device must first be defined in the NetLinx programming language with values for the Device: Port: System (in
all programming examples - Panel is used in place of these values and represents all Modero panels).
Button Assignments
Page Commands
These Page Commands are used in NetLinx Programming Language and are case insensitive.
Verify you are using the latest NetLinx Master and Modero touch panel firmware.
Verify you are also using the latest version of TPDesign4.
• Button Channel Range: 1 - 4000 Button push and Feedback (per address port)
• Button Variable Text range: 1 - 4000 (per address port)
• Button States Range: 1 - 256 (0 = All states, for General buttons 1 = Off state and 2 = On state).
• Level Range: 1 - 600 (Default level value 0 - 255, can be set up to 1 - 65535)
• Address port Range: 1 - 100
These button assignments can only be adjusted in TPD4 and not on the panels
themselves.
Page Commands
@APG Add the popup page to a group if it does not already exist. If the new popup is added to a group which
has a popup displayed on the current page along with the new pop-up, the displayed popup will be
hidden and the new popup will be displayed.
Syntax:
"'@APG-<popup page name>;<popup group name>'"
Variable:
popup page name = 1 - 50 ASCII characters. Name of the popup page.
popup group name = 1 - 50 ASCII characters. Name of the popup group.
Example:
SEND_COMMAND Panel,"'@APG-Popup1;Group1'"
Adds the popup page ’Popup1’ to the popup group ’Group1’.
@CPG Clear all popup pages from specified popup group.
Syntax:
"'@CPG-<popup group name>'"
Variable:
popup group name = 1 - 50 ASCII characters. Name of the popup group.
Example:
SEND_COMMAND Panel,"'@CPG-Group1'"
Clears all popup pages from the popup group ’Group1’.
