AMX NXD-1200V

Firmware Pages and Descriptions
95
NXD/T-1200V Wall/Flush Mount Touch Panel
Refer to the Using G4 Web Control to Interact with a G4 Panel section on page 64 for more detailed instructions on how
to use the G4 Web Control page with the new web-based NetLinx Security application.
Sensor Setup Page
The Sensor Setup page (FIG. 97) allows you to adjust the Light and Motion Sensor parameters on a Modero touch panel.
G4 Web Control Page Elements (Cont.)
Web Control Name Allows you to enter a unique alpha-numeric string that is used as the display name of the
panel within the Manage WebControl Connections window of the new NetLinx Security
browser window.
• This Web Control tab displays a G4 icon alongside the link to the Web Control Name
given to this panel (FIG. 96).
Web Control Password Allows you to enter the G4 Authentication session password associated for VNC web
access of this panel.
Web Control Port Allows you to enter the port value that the VNC Web Server runs on.
• Default value is 5900.
Maximum Number of
Connections
This read-only field displays the maximum number of users that can be
simultaneously connected to the target panel via the web.
• Default value is 1.
Current Connection Count This read-only field displays the current number of users connected to the
target panel via the web. This value cannot exceed the Maximum number field.
G4 Web Control Timeout: Sets the length of time (in minutes) the panel can remain idle (no cursor
movements) before the session is closed and the user is disconnected.
• Minimum value = 0 minutes (panel never times-out)
• Maximum value = 240 minutes (panel times-out after 240 minutes/4hours)
FIG. 96
Sample relationship between G4 Web Control and Mange WebControl Connections window
FIG. 97 Sensor Setup page
