AMX NXD-1200V

Firmware Pages and Descriptions
96
NXD/T-1200V Wall/Flush Mount Touch Panel
The elements of the Sensor Setup page are described in the table below:
A light level value between the Minimum and Maximum DIM Mode values delivers an
average light level. The DIM mode Min Level can never exceed the DIM Mode Max
Level.
Sensor Setup Page Elements
Back: Saves the changes and returns you to the previously active touch panel page.
Connection Status icon: This visual display of the connection status allows the user to have a current visual update of
the panel’s connection status regardless of what page is currently active.
• A Lock only appears on the icon if the panel has established a connection with a currently
secured target Master (requiring a username and password).
Light Sensor: Allows you to monitor and alter the sensitivity of the Modero panel light sensor:
•The Light Sensor Level field indicates the level used to report the light sensor level back
to the NetLinx Master (set in TPD4) (read-only).
•The Light Sensor Level Port field indicates the port used to report the light sensor level
back to the NetLinx Master (set in TPD4) (read-only).
•The Light Sensor Channel field indicates the level used to report the sensor channel
back to the NetLinx Master (set in TPD4). It is On when you are below the Maximum dim
mode level (read-only).
•The Light Sensor Channel Port field indicates the port used to report the sensor channel
back to the NetLinx Master (set in TPD4) (read-only).
•The Light Level field provides a numeric value representing the current value of the light
level detected by the on-board photo-sensor.
• The Light Level bargraph displays a horizontal bargraph indicating the current value of the
light level detected by the on-board photo-sensor. This bargraph provides a visual
representation of the numeric value displayed within the Light Level field.
• Use the Dim Mode Max Level bargraph to alter the Maximum DIM level value used to
activate the DIM Mode Brightness Level (range = 0 - 100).
• Use the Dim Mode Min Level bargraph to alter the Minimum DIM level value used to
activate the DIM Mode Brightness Level (range = 0 - 100).
- The position of this bargraph can never exceed that of the Dim Mode
Max Level.
Motion Sensor: Provides the following fields:
•The Motion Detection field displays a reactive button that changes color (illuminates) and
displays the words "Motion Detected" when motion is detected by the Modero panel’s front
motion sensor.
•The Motion Sensor Port field indicates the port used to report the motion sensor channel
back to the NetLinx Master (set in TPD4) (read-only).
•The Motion Sensor Channel field indicates the channel used to report the motion sensor
channel back to the NetLinx Master (set in TPD4) (read-only).
Wake Panel On Motion
Sense:
The Wake Panel Sensitivity relates to the sensitivity of the motion sensor to detect motion and
wake the panel accordingly.
• Toggle the Enable/Enabled button to either active/inactive this feature:
- Enable - activates this feature. Activating this feature reactivates the panel from a panel
timeout (sleep) mode.
- Enabled - (illuminated when selected) deactivates this feature and makes the panel use
the specified Display Timeout value set on the Setup Page.
• Use the Wake Panel UP/DN buttons to alter the sensitivity value. Range = 0 - 100.
• The horizontal WAKE PANEL SENSITIVITY bargraph indicates the current motion
sensitivity value associated with waking the panel from a timeout.
