AMX NXD-1200V

Programming
112
NXD/T-1200V Wall/Flush Mount Touch Panel
Font Styles and ID Numbers
Font styles can be used to program the text fonts on buttons, sliders, and pages. The following chart shows the default
font type and their respective ID numbers generated by TPDesign4.
Border styles
The TPDesign4 Touch Panel Design program has pre-set border styles that are user selectable. TPD4 border styles can
ONLY be changed by using the name.
RGB Values for all 88 Basic Colors (Cont.)
Index No. Name Red Green Blue
71 Very Dark Pink 95 0 48
72 White 255 255 255
73 Grey1 238 238 238
74 Grey3 204 204 204
75 Grey5 170 170 170
76 Grey7 136 136 136
77 Grey9 102 102 102
78 Grey4 187 187 187
79 Grey6 153 153 153
80 Grey8 119 119 119
81 Grey10 85 85 85
82 Grey12 51 51 51
83 Grey13 34 34 34
84 Grey2 221 221 221
85 Grey11 68 68 68
86 Grey14 17 17 17
87 Black 0 0 0
255 TRANSPARENT 99 53 99
Default Font Styles and ID Numbers
Font ID # Font type Size Font ID # Font type Size
1 Courier New 9 19 Arial 9
2 Courier New 12 20 Arial 10
3 Courier New 18 21 Arial 12
4 Courier New 26 22 Arial 14
5 Courier New 32 23 Arial 16
6 Courier New 18 24 Arial 18
7 Courier New 26 25 Arial 20
8 Courier New 34 26 Arial 24
9 AMX Bold 14 27 Arial 36
10 AMX Bold 20 28 Arial Bold 10
11 AMX Bold 36 29 Arial Bold 8
32 - Variable Fonts start at 32.
You must import fonts into a TPDesign4 project file. The font ID numbers are
assigned by TPDesign4. These values are also listed in the
Generate Programmer’s Report.
TPD4 Border Styles by Name
Border styles Border styles
None Diamond 55
AMX Elite -L Diamond 65
AMX Elite -M Diamond 75
AMX Elite -S Double Bevel -L
Bevel -L Double Bevel -M
Bevel -M Double Bevel -S
Bevel -S Double Line
Circle 15 Fuzzy
Circle 25 Glow-L
