AMX NXD-1200V

Programming
110
NXD/T-1200V Wall/Flush Mount Touch Panel
Programming Numbers
The following information provides the programming numbers for colors, fonts, and borders.
Colors can be used to set the colors on buttons, sliders, and pages. The lowest color number represents the lightest color-
specific display; the highest number represents the darkest display.
For example, 0 represents light red, and 5 is dark red.
RGB Triplets And Names For Basic 88 Colors
Page Commands (Cont.)
PPOG Toggle a specific popup page on either a specified page or the current page. If the page name is
empty, the current page is used (see example 2). Toggling refers to the activating/deactivating (On/
Off) of a popup page. This command works in the same way as the ’Toggle Popup’ command in
TPDesign4.
Syntax:
"'PPOG-<popup page name>;<page name>'"
Variable:
popup page name = 1 - 50 ASCII characters. Name of the popup page.
page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.
Example:
SEND_COMMAND Panel,"'PPOG-Popup1;Main'"
Toggles the popup page ’Popup1’ on the Main page from one state to another (On/Off).
Example 2:
SEND_COMMAND Panel,"'PPOG-Popup1'"
Toggles the popup page ’Popup1’ on the current page from one state to another (On/Off).
PPON Activate a specific popup page to launch on either a specified page or the current page. If the page
name is empty, the current page is used (see example 2). If the popup page is already On, do not re-
draw it. This command works in the same way as the ’Show Popup’ command in TPDesign4.
Syntax:
"'PPON-<popup page name>;<page name>'"
Variable:
popup page name = 1 - 50 ASCII characters. Name of the popup page.
page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.
Example:
SEND_COMMAND Panel,"'PPON-Popup1; Main'"
Activates the popup page ’Popup1’ on the Main page.
Example 2:
SEND_COMMAND Panel,"'PPON-Popup1'"
Activates the popup page ’Popup1’ on the current page.
RGB Values for all 88 Basic Colors
Index No. Name Red Green Blue
00 Very Light Red 255 0 0
01 Light Red 223 0 0
02 Red 191 0 0
03 Medium Red 159 0 0
04 Dark Red 127 0 0
05 Very Dark Red 95 0 0
06 Very Light Orange 255 128 0
07 Light Orange 223 112 0
08 Orange 191 96 0
09 Medium Orange 159 80 0
10 Dark Orange 127 64 0
11 Very Dark Orange 95 48 0
12 Very Light Yellow 255 255 0
13 Light Yellow 223 223 0
14 Yellow 191 191 0
