AMX NXD-1200V

Programming
149
NXD/T-1200V Wall/Flush Mount Touch Panel
Dynamic Image Commands
The following table describes Dynamic Image Commands.
Dynamic Image Commands
^BBR Set the bitmap of a button to use a particular resource.
Syntax:
"'^BBR-<vt addr range>,<button states range>,<resource name>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
resource name = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^BBR-700,1,Sports_Image'"
Sets the resource name of the button to ’Sports_Image’.
^RAF Add new resources. Adds any and all resource parameters by sending embedded codes and data. Since the
embedded codes are preceded by a '%' character, any '%' character contained in the URL must be escaped with
a second '%' character (see example).
The file name field (indicated by a %F embedded code) may contain special escape sequences as shown in the
^RAF, ^RMF - Embedded Codes table below.
Syntax:
"'^RAF-<resource name>,<data>'"
Variables:
• resource name = 1 - 50 ASCII characters.
• data = Refers to the embedded codes, see the ^RAF, ^RMF - Embedded Codes section on page 150.
Example:
SEND_COMMAND Panel,"'^RAF-New Image,%P0%HAMX.COM%ALab/Test%%5Ffile%Ftest.jpg'"
Adds a new resource.
• The resource name is ’New Image’
• %P (protocol) is an HTTP
• %H (host name) is AMX.COM
• %A (file path) is Lab/Test_file
• %F (file name) is test.jpg.
Note that the %%5F in the file path is actually encoded as %5F.
^RFR Force a refresh for a given resource.
Syntax:
"'^RFR-<resource name>'"
Variable:
resource name = 1 - 50 ASCII characters.
Example:
SEND_COMMAND Panel,"'^RFR-Sports_Image'"
Forces a refresh on ’Sports_Image’.
