AMX NXD-1200V

Programming
120
NXD/T-1200V Wall/Flush Mount Touch Panel
"^" Button Commands (Cont.)
^BMF
(Cont.)
’%GI<bargraph invert>’ = Set the bargraph invert/noninvert or joystick coordinate (0,1,2,3). ^GIV section
on page 127 more information.
’%GU<bargraph ramp up>’ = Set the bargraph ramp up time in intervals of 1/10 second.
’%GD<bargraph ramp down>’ = Set the bargraph ramp down time in 1/10 second.
’%GG<bargraph drag increment> = Set the bargraph drag increment. Refer to the ^GDI command on
page 127 for more information.
’%VI<video On/Off>’ = Set the Video either On (value=1) or Off (value=0).
’%OT<feedback type>’ = Set the Feedback (Output) Type to one of the following:
None, Channel,Invert, On (AlwaysOn), Momentary, or Blink.
’%SM’ = Submit a text for text area button.
’%SF<1 or 0>’ = Set the focus for text area button.
’%OP<0-255>’ = Set the button opacity to either Invisible (value=0) or Opaque (value=255).
’%OP#<00-FF>’ = Set the button opacity to either Invisible (value=00) or Opaque (value=FF).
’%UN<Unicode text>’ = Set the Unicode text. See the^UNI section on page 132 for the text format.
’%LN<0-240>’ = Set the lines of video being removed. See the^BLN section on page 117 for more
information.
’%EF<text effect name>’ = Set the text effect.
’%EC<text effect color>’ = Set the text effect color.
’%ML<max length>’ = Set the maximum length of a text area.
’%MK<input mask>’ = Set the input mask of a text area.
’%VL<0-1>’ = Log-On/Log-Off the computer control connection
’%VN<network name>’ = Set network connection name.
’%VP<password>’ = Set the network connection password.
Example:
SEND_COMMAND Panel,"'^BMF-500,1,%B10%CFRed%CB Blue
%CTBlack%Ptest.png'"
Sets the button OFF state as well as the Border, Fill Color, Border Color, Text Color, and Bitmap.
