Installation Procedures: NXD-1200V Panels
36
NXD/T-1200V Wall/Flush Mount Touch Panel
3. Remove the magnetic faceplate/bezel (A in FIG. 40) from the main NXD unit (B in FIG. 40) by gripping the
faceplate and pulling with gentle outward force.
FIG. 39 NXD-1200V 12-inch Wall Mount panel dimensions using expansion clips
FRONT BEZEL
CUTOUT
