5-3 :Display Subsystem VNA Commands
5-36 PN: 10580-00319 Rev. N S412E PM
:DISPlay:WINDow:TRACe<Tr>:Y[:SCALe]:PDIVision <value>
:DISPlay:WINDow:TRACe<Tr>:Y[:SCALe]:PDIVision?
Description: Sets the scale per division for the y-axis. For Group Delay, sets the scale
(time/division) for the y-axis. For Phase, sets the scale (degree/division)
for the y-axis. For Log Magnitude and Log Mag/2, sets the scale
(dB/division) for the y-axis. For all other measurements, the y-axis is
unitless. <Tr> is the trace number in the range 1 to 4. If no trace
number is specified, then the <Tr> parameter defaults to trace
number 1.
Cmd Parameter: <NRf> <value> (depends on display type)
Query Response: <NR3> <value> (depends on display type)
Default Value: Log Magnitude: 10 dB
Phase: 45°
SWR: 1
Group Delay: 1 ns
Real: 0.2
Imag: 0.2
Log Mag/2: 10 dB
Smith Chart: 10
Log Polar: 10 dB
Linear Polar: 0.2
Real Impedance: 10 ohm
Imaginary Impedance: 10 ohm
Default Unit: Current active value unit (For time, the default for setting is seconds,
but the query is always returned in nanoseconds (ns).)
Range: Log Magnitude: 0.05 dB to 40 dB
Phase: 0.1° to 90°
SWR: 0.001 to 10
Group Delay: 1ps to 260ns
Real: 0.01 to 260
Imag: 0.01 to 260
Log Mag/2: 0.05 dB to 40 dB
Smith Chart: 1 to 260
Log Polar: 0.05 dB to 40 dB
Linear Polar: 0.001 to 26
Real Impedance: 0.01 ohm to 260 ohm
Imaginary Impedance: 0.01 ohm to 260 ohm
Front Panel Access: Scale, Resolution Per Div
Note
Although these values are not used for Smith Chart, when you query or set through
SCPI, the instrument always returns a value. For Smith Chart, use
:DISPlay:WINDow:TRACe<Tr>:Y[:SCALe]:SMCHart 0|10|20|30|–3
