VNA Commands 5-7 :MMEMory Subsystem
S412E PM PN: 10580-00319 Rev. N 5-49
:MMEMory:STORe:STATe <integer>, <file name>
Description: Stores the current setup into the file that is specified by
<file name>. <file name> must be enclosed in either single quotes
(‘ ’) or double quotes (“ ”) and must not contain a file extension. The
<integer> is used to distinguish whether the calibration should be
saving with the setup. Send a 1 to save setup without a calibration.
Send a 2 to save setup with calibration.
Cmd Parameter: <integer>, <string> (1|2, filename)
Query Response: NA (no query)
Front Panel Access: NA
:MMEMory:STORe:TRACe <integer>, <file name>
Description: Stores the trace into the file that is specified by <file name>.
<file name> must be enclosed in either single quotes (‘ ’) or double
quotes (“ ”) and must not contain a file extension. The <integer>
parameter is used to distinguish which type of files to save. The
following types are available:
Cmd Parameter: <integer>, <string> (1|2, filename)
Query Response: NA (no query)
Example: To save the trace into the file named “trace”.
:MMEMory:STORe:TRACe 1,”trace”
Related Command: :MMEMory:LOAD:TRACe
Front Panel Access: Shift-7 (File), Save
Shift-7 (File), Save Measurement
<Integer> Equivalent File type
1 Measurement file (default, if number is not 1 to 6)
2 S2P Real/Imag
3 S2P Lin Mag/Phase
4 S2P Log Mag/Phase
5Text
6CSV
