5-10 :Trace Subsystem VNA Commands
5-60 PN: 10580-00319 Rev. N S412E PM
TRACE_x_SWR_RESOLUTION SWR Resolution, where x is the trace number.
Returned value is 1000 times the SWR
Resolution.
TRACE_x_SWR_REFERENCE SWR Reference value, where x is the trace
number. Returned value is 1000 times the SWR
Reference value.
TRACE_x_SWR_REFERENCE_LINE SWR Reference Line, where x is the trace
number.
TRACE_x_PHASE_RESOLUTION Phase Resolution, where x is the trace number.
Returned value is 1000 times the phase
resolution.
TRACE_x_PHASE_REFERENCE Phase Reference value, where x is the trace
number. Returned value is 1000 times the phase
reference value.
TRACE_x_PHASE_REFERENCE_LINE Phase Reference Line, where x is the trace
number.
TRACE_x_REAL_RESOLUTION Real Resolution, where x is the trace number.
Returned value is 1000 times the
resolution per div value.
TRACE_x_REAL_REFERENCE Real Reference value, where x is the trace
number. Returned value is 1000 times the
reference value.
TRACE_x_REAL_REFERENCE_LINE Real Reference line, where x is the trace number.
TRACE_x_IMAG_RESOLUTION Imaginary Resolution, where x is the trace
number. Returned value is 1000 times the
reference value.
TRACE_x_IMAG_REFERENCE Imaginary Reference value, where x is the trace
number. Returned value is 1000 times the
reference value.
TRACE_x_IMAG_REFERENCE_LINE Imaginary Reference line, where x is the trace
number.
TRACE_x_GD_RESOLUTION Group Delay Resolution, where x is the trace
number. Returns in units of picoseconds.
TRACE_x_GD_REFERENCE Group Delay Reference value, where x is the
trace number. Returns in units of picoseconds.
TRACE_x_GD_REFERENCE_LINE Group Delay Reference line, where x is the trace
number.
TRACE_x_SMITH_SCALE Currently not used.
TRACE_x_SMITH_IMPEDANCE Currently not used.
TRACE_x_SMITH_IMPEDANCE_LINE Currently not used.
Table 5-3. Trace Header Parameters (Sheet 7 of 8)
Parameter Name Description
