VNA Commands 5-10 :Trace Subsystem
S412E PM PN: 10580-00319 Rev. N 5-61
TRACE_x_1PCL_RESOLUTION Log Mag/2 resolution, where x is the trace
number. Returned value is in dB.
TRACE_x_1PCL_REFERENCE Log Mag/2 Reference value, where x is the trace
number. Returned value is in dB.
TRACE_x_1PCL_REFERENCE_LINE Log Mag/2 Reference line, where x is the trace
number.
TRACE_x_POLAR_RESOLUTION Currently not used.
TRACE_x_POLAR_REFERENCE Currently not used.
TRACE_x_POLAR_REFERENCE_LINE Currently not used.
CAL_METHOD Calibration Method, where:
SOLT = 0
CAL_TYPE The index of the selected calibration type list,
where 0 is the first in the list.
CAL_LINE_TYPE Calibration Line Type, where coax = 0.
CAL_PORTx_DUT The index of the selected Calibration Coax DUT
Selector list for port x, where 0 is the first in the
list.
CAL_CORRECTION Calibration correction, where On = 0, and Off = 1
APP_SELF_TEST_MODE Internal use only
DEBUG_MEAS_GAIN_RANGE Internal use only
LOG_COUNTER_EVENTS Internal use only
SWEEP_DEFAULT_FREQS Internal use only
PWRCAL_RF_SWITCH_FREQ Internal use only
PWRCAL_LOW_RF_HIGH_TARGET Internal use only
PWRCAL_LOW_RF_LOW_TARGET Internal use only
PWRCAL_UPPER_RF_HIGH_TARGET Internal use only
PWRCAL_UPPER_RF_LOW_TARGET Internal use only
PWRCAL_UW_RF_HIGH_TARGET Internal use only
PWRCAL_UW_RF_LOW_TARGET Internal use only
USER_DEFINED_CAL_KIT_NAME Internal use only
USER_DEFINED_CAL_KIT Internal use only
TRACE_LABEL_STATE Trace label On/Off, where On = 0, Off = 1
Table 5-3. Trace Header Parameters (Sheet 8 of 8)
Parameter Name Description
