DMR 2 Commands 14-11 :TRACe Subsystem
S412E PM PN: 10580-00319 Rev. N 14-33
SYMBOL
Number of symbols shown in the horizontal axis of the
Analyzer Eye Diagram.
RECEIVER_UNITS Receiver unit type. 0 is dBm, 1 is Watts, 2 is Volts.
GENERATOR_UNITS Generator unit type. 0 is dBm, 1 is Watts, 2 is Volts.
GENERATOR_OUTPUT State of the signal generator. 0 is ON and 1 is OFF.
GENERATOR_FREQ Frequency of the signal generator.
GENERATOR_PATTERN
Pattern that the signal generator is outputting. The
value corresponds to the index (starting from 0) of the
list returned from issuing a
:SOURce:DM:PATTern:LIST? command.
GENERATOR_OUTPUT_LVL Output power level of the signal generator.
GENERATOR_OUTPUT_LVL_BK
Backup generator power level. Used to store original
generator power level when Tx Power Offset is
applied.
HEX_TRIGGER
State of hex triggering for Control Channel. 0 is ON
and 1 is OFF.
HEX_TRIGGER_VALUE
When value is detected in the first octet of a Control
Channel packet, the unit will be put into Hold mode.
COUPLING State of frequency coupling. 0 is ON and 1 is OFF.
FREQ_COUPLING_OFFSET
Amount that the Receiver (Rx) and Generator (Tx)
frequency is offset by when frequency coupling is ON.
GENERATOR_LVL_OFFSET Generator (Tx) power offset.
SQUELCH Squelch level for the Analyzer summary window.
SQUELCH_BK
Backup value for squelch level when Receiver Power
Offset is applied.
SPAN Receiver (Rx) span.
AVERAGING
Number of times numerics in the summary window are
averaged.
AM_PERCENTAGE Percentage for the am_1khz_audio generator pattern.
FM_DEVIATION Deviation for the fm_1khz_audio generator pattern.
NAC Not used.
NAC_BK Not used.
RSSI_MAPPING_EXCELLENT
Threshold at which the RSSI mapping value is
deemed excellent (Only used in P25, P25p2, NXDN,
dPMR, DMR2, PTC).
RSSI_MAPPING_VERY_GOOD
Threshold at which the RSSI mapping value is
deemed very good (Only used in P25, P25p2, NXDN,
dPMR, DMR2, PTC).
Table 14-1. Returned Parameter Values in Trace Preamble (Sheet 4 of 7)
Parameter Name Description
