14-11 :TRACe Subsystem DMR 2 Commands
14-32 PN: 10580-00319 Rev. N S412E PM
TRACE_GRAPH_TYPES_TOC
Backup trace graph type for Coverage (Not in use with
new mapping style).
ACTIVE_GRAPH Selected graph.
ACTIVE_GRAPH_TX Backup active graph for Analyzer.
ACTIVE_GRAPH_TOC
Backup active graph for Coverage (Not in use with
new mapping style).
MAXIMIZE_GRAPH
Determines whether active graph is maximized or
minimized.
MAXIMIZE_GRAPH_TX Backup maximize graph for Analyzer.
MAXIMIZE_GRAPH_TOC
Backup maximize graph for Coverage (Not in use with
new mapping style).
TOTAL_GRAPHS
Total graphs shown on the screen when minimized.
Analyzer is hard coded to 4 graphs.
MEAS_TYPE
Measurement type.
0 = Analyzer
1 = Not used
2 = Control (Only used in P25, P25p2, NXDN, DMR2)
3= Bit Capture (Only used in P25, P25p2, NXDN,
DMR2)
4 = Coverage
5 = NBFM Quieting (Only used in NBFM)
6 = NBFM SINAD (Only used in NBFM)
EXTERNAL_REFERENCE Not used.
REFERENCE_FREQUENCY
The frequency to which the external reference is
locked.
MEAS_DISPLAY
State of the numerical display window in the Coverage
measurement.
MEAS_DISPLAY_TX Backup measurement display for Analyzer.
MEAS_DISPLAY_TOC
Backup measurement display for Coverage (Not in
use with new mapping style).
PATTERN Receiver (Rx) pattern.
DYNAMIC_ATTENUATION
Auto receiver (Rx) range. Determines if reference
level is automatically adjusted according to the
receiver input signal.
LOG_TYPE Auto logging type (Not in use with new mapping style).
KML_FLAG_LABEL Not used.
KML_FLAG_TIME Not used.
Table 14-1. Returned Parameter Values in Trace Preamble (Sheet 3 of 7)
Parameter Name Description
