Spectrum Analyzer Commands 4-9 :MMEMory Subsystem
S412E PM PN: 10580-00319 Rev. N 4-33
:MMEMory:LOAD:TRACe <integer>,<file name>
Title: Recall Measurement
Description: The instrument must be in the mode of the saved trace in order to recall
that trace. Use :INSTrument:SELect or :INSTrument:NSELect to set
the mode. Recalls a previously stored measurement trace from the
current save location. The saved measurement trace to be loaded is
specified by <file name>. <file name> should be enclosed in either single
quotes (‘ ’) or double quotes (“ ”) and should contain a file extension.
Note that the trace specified by <file name> should be available at the
current save location. Use the command MMEMory:MSIS to set the
current save location. The <integer> parameter is not currently used,
but it must be sent. Send a 1.
File name extensions:
“.spa” for SPA measurement
“.mna” for VNA and VVM measurements
“.hipm” for HiPM measurements
“.pm” for PM measurements
“.cwsg” for CWSG measurements
“.afp” for AM/FM/PM measurements
“.ia” for Interference Analysis measurements
“.cs” for Channel Scanner measurements
“.wmxd” for WiMAX
“.wmxe” for Mobile WiMAX
“.lte” for LTE measurements
“.p25” for P25 measurements
“.p252” for P25p2 measurements
“.nxdn” for NXDN measurements
“.dpmr” for dPMR measurements
“.dmr2” for DMR 2 measurements
“.ptc” for PTC measurements
“.tetra” for TETRA measurements
“.nbfm” for NBFM measurements
Parameter: <integer>,<file name>
Example: To recall trace with file name “trace”:
:MMEMory:LOAD:TRACe 1,”trace.spa”
Related Command: :MMEMory:STORe:TRACe
:MMEMory:MSIS INTernal|USB
Front Panel Access: Shift-7 (File), Recall Measurement
Note
This command requires front panel access to select the trace and to complete the
command.
