Performance Verification 2 3-12 EVDO Signal Analyzer Option Verification (Options 62 and 63)
MS2721B MM PN: 10580-00177 Rev. D 3-69
EVDO Signal Analyzer
Figure 3-19. EVDO Signal Analyzer Test Setup
Function
Ethernet Control Input Modulation Input
Cursor/Edit
RF Output
3
MG3700
Vector Signal
Generator
250kHz-6GHz
MG3700A
ML2438A Power Meter
10 MHz Reference
To Ext Ref In
(to back panel)
Power
Splitter 1870A
Adapter
N(m) to N(m)
MS2721B
Power Sensor
MA2482D
Adapter
AUX Input/Output
Connector 1
Ext
Trigger In
15NNF50-1.5B
