Anritsu Spectrum Master MS2721B Maintenance Manual

A-8 PN: 10580-00177 Rev. D MS2721B MM
Spectrum Analyzer Amplitude Accuracy Verification (continued)
Amplitude Accuracy Across Frequency Verification
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-21. Characterization Chart for Fixed Level with Varying Frequency, Amplitude Accuracy
Frequency –2 dBm –30 dBm
10.1 MHz dBm dBm
50 MHz dBm dBm
100 MHz dBm dBm
500 MHz dBm dBm
1000 MHz dBm dBm
2000 MHz dBm dBm
3000 MHz dBm dBm
4000 MHz dBm dBm
5000 MHz dBm dBm
6000 MHz dBm dBm
7000 MHz dBm dBm
Table A-22. Amplitude Accuracy Across Frequency Verification at 10.1 MHz
Input Power Attenuation Level Marker 1 Reading Specification
–30dBm 0dB dBm ±1.25dB
–30dBm 5dB dBm ±1.25dB
–30 dBm 10 dB dBm ± 1.25 dB
–30 dBm 20 dB dBm ± 1.25 dB
–2dBm 30dB dBm ±1.25dB
–2dBm 40dB dBm ±1.75dB
–2dBm 50dB dBm ±1.75dB
–2dBm 60dB dBm ±1.75dB
