Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-7
Spectrum Analyzer Amplitude Accuracy Verification
50 MHz Amplitude Accuracy Verification
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-19. Characterization Chart for 50 MHz Amplitude Accuracy Verification
Test Power level at 50 MHz Required Sensor B Reading
0dBm dBm
–4 dBm dBm
–10 dBm dBm
–14 dBm dBm
–20 dBm dBm
–24 dBm dBm
–30 dBm dBm
–34 dBm dBm
–40 dBm dBm
–44 dBm dBm
–50 dBm dBm
Table A-20. 50 MHz Amplitude Accuracy Verification
Input Power
Level
Reference
Level
Input Attenuation
Level Measured Reading Specification
0 dBm 10 dBm 30 dB dBm ± 1.25 dBm
–4 dBm 10 dBm 30 dB dBm ± 1.25 dBm
–10 dBm 0 dBm 20 dB dBm ± 1.25 dBm
–14 dBm 0 dBm 20 dB dBm ± 1.25 dBm
–20 dBm –10 dBm 10 dB dBm ± 1.25 dBm
–24 dBm –10 dBm 10 dB dBm ± 1.25 dBm
–30dBm –20dBm 0dB dBm ±1.25dBm
–34dBm –20dBm 0dB dBm ±1.25dBm
–40dBm –30dBm 0dB dBm ±1.25dBm
–44dBm –30dBm 0dB dBm ±1.25dBm
–50dBm –40dBm 0dB dBm ±1.25dBm
