Anritsu Spectrum Master MS2721B Maintenance Manual

A-12 PN: 10580-00177 Rev. D MS2721B MM
Amplitude Accuracy Across Frequency Verification (continued)
9 kHz to 100 kHz Amplitude Accuracy Verification
Characterization Charts
Test Results
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-32. Amplitude Accuracy Across Frequency Verification at 7000 MHz
Input Power Attenuation Level Marker 1 Reading Specification
–30dBm 0dB dBm ±1.75dB
–30dBm 5dB dBm ±1.75dB
–30 dBm 10 dB dBm ± 1.75 dB
–30 dBm 20 dB dBm ± 1.75 dB
–2dBm 30dB dBm ±1.75dB
–2 dBm 40 dB dBm ± 2 dB
–2 dBm 50 dB dBm ± 2 dB
–2 dBm 60 dB dBm ± 3 dB
Table A-33. Measured VM1, –20 dBm Reference voltage at 100 kHz (23.315 mV ± 0.5 mV)
Measured VM1
mV
Table A-34. Characterization Chart for 9 kHz to 100 kHz Amplitude Accuracy Verification
Frequency Measured VM2 Correction Factor Calculated P
in
9.5 kHz mV 0.047 dB dBm
55 kHz mV 0.002 dB dBm
95 kHz mV 0.000 dB dBm
Table A-35. 9 kHz to 100 kHz Amplitude Accuracy Verification
At Freq Calculated P
in
Marker 1 Reading Error Specification
9.5 kHz dBm dBm dB ± 1.5 dB
55 kHz dBm dBm dB ± 1.5 dB
95 kHz dBm dBm dB ± 1.5 dB
