Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-39
Option 63 EVDO Demodulator
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-120.EVDO Demodulator at 870.03 MHz, –50 dBm Level, 921.6 kps 8-PSK Modulation, Option 63
Measured Value Specification
Frequency Error
Hz ± 20 Hz
Rho Pilot
0.99 ≤ x ≤ 1
Tau
µs ± 1 µs
Table A-121.EVDO Demodulator At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation, Option 63
Measured Value Specification
Frequency Error
Hz ± 20 Hz
Rho Pilot
0.99 ≤ x ≤ 1
Tau
µs ± 1 µs
Table A-122.EVDO Demodulator At 1930.05 MHz, –50 dBm Level, 2457.6 kps 16-QAM Modulation, Option 63
Measured Value Specification
Frequency Error
Hz ± 20 Hz
Rho Pilot
0.99 ≤ x ≤ 1
Tau
µs ± 1 µs
Table A-123.EVDO Demodulator At 1930.05 MHz, –50 dBm Level, Idle Slot, Option 63
Measured Value Specification
Frequency Error
Hz ± 20 Hz
Rho Pilot
0.99 ≤ x ≤ 1
Tau
µs ± 1 µs
Table A-124.EVDO Demodulator At 870.03 MHz, –10 dBm Level, Idle Slot, Option 63
Measured Value Specification
Frequency Error
Hz ± 20 Hz
Rho Pilot
0.99 ≤ x ≤ 1
Tau
µs ± 1 µs
