Anritsu Spectrum Master MS2721B Maintenance Manual

A-4 PN: 10580-00177 Rev. D MS2721B MM
Spectrum Analyzer DANL
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-8. Spectrum Analyzer DANL (Pre Amp On)
Start
Frequency
Stop
Frequency RBW VBW
Measured Power
(100k RBW)
Calculated Power
(1 Hz RBW)
1Hz
Specification
10 MHz 1.0 Ghz 100 kHz 1 kHz dBm dBm ≥ –161 dBm
1.0GHz 2.2GHz 100kHz 1kHz dBm dBm ≥ –159 dBm
2.2 GHz 2.8 GHz 100 kHz 300 Hz dBm dBm ≥ –153 dBm
2.8 GHz 4.0 GHz 100 kHz 300 Hz dBm dBm ≥ –159 dBm
4.0 GHz 7.1 GHz 100 kHz 300 Hz dBm dBm ≥ –154 dBm
Table A-9. Spectrum Analyzer DANL (Pre Amp Off)
Start
Frequency
Stop
Frequency RBW VBW
Measured Power
(100k RBW)
Calculated Power
(1 Hz RBW)
1Hz
Specification
10 MHz 1.0 Ghz 100 kHz 1 kHz dBm dBm ≥ –137 dBm
1.0GHz 2.2GHz 100kHz 1kHz dBm dBm ≥ –133 dBm
2.2 GHz 2.8 GHz 100 kHz 300 Hz dBm dBm ≥ –126 dBm
2.8 GHz 4.0 GHz 100 kHz 300 Hz dBm dBm ≥ –136 dBm
4.0 GHz 7.1 GHz 100 kHz 300 Hz dBm dBm ≥ –127 dBm
