A-2 PN: 10580-00177 Rev. D MS2721B MM
Spectrum Analyzer Function Verification
Spectrum Analyzer Frequency Accuracy
Spectrum Analyzer SSB Phase Noise Verification
Spectrum Analyzer Resolution Bandwidth Accuracy
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-1. Spectrum Analyzer Frequency Accuracy
Frequency Measured Value Error Specification
1 GHz GHz Hz ± 1,300 Hz
7GHz GHz Hz ±9.1kHz
Table A-2. Spectrum Analyzer SSB Phase Noise Verification
Frequency Measured Value Specification
10 kHz dBc/Hz –100 dBc/Hz
20 kHz dBc/Hz –100 dBc/Hz
30 kHz dBc/Hz –100 dBc/Hz
100 kHz dBc/Hz –100 dBc/Hz
Table A-3. Spectrum Analyzer Resolution Bandwidth Accuracy
RBW Setting Span VBW Measured Value Specification
3MHz 4.5MHz Auto Hz 2.7MHz to 3.3MHz
1MHz 1.5Mhz Auto Hz 900kHz to 1.1MHz
300kHz 450kHz Auto Hz 270kHz to 330kHz
100kHz 150kHz Auto Hz 90kHz to 110kHz
30 kHz 45 kHz Auto Hz 27 kHz to 33 kHz
10 kHz 15 kHz Auto Hz 9 kHz to 11 kHz
3kHz 4.5kHz Auto Hz 2.7kHz to 3.3kHz
1kHz 2kHz Auto Hz 900Hz to 1.1kHz
300 Hz 450 Hz Auto Hz 270 Hz to 330 Hz
100 Hz 150 Hz Auto Hz 90 Hz to 110 Hz
30 Hz 50 Hz 3 Hz Hz 27 Hz to 33 Hz
10 Hz 30 Hz 3 Hz Hz 9 Hz to 11 Hz
