Anritsu Spectrum Master MS2721B Maintenance Manual

A-48 PN: 10580-00177 Rev. D MS2721B MM
Option 66 Mobile WiMAX RF Measurements (continued)
Mobile WiMAX Channel Power Accuracy (5 MHz BW and 5 ms Frame Length)
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-148.Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –15.0 dBm) Option 66
Measured Value Specification
Power Meter Reading
dBm –15 dBm ± 0.2 dB
MS272xB Reading
dBm –15 dBm ± 0.2 dB
Calculated Channel
Power Error
dB ±1.5 dB
Table A-149.Mobile WiMAX Channel Power Accuracy Power Error (2600.5 MHz and –50.0 dBm) Option 66
Measured Value Specification
Power Meter Reading
dBm –50 dBm ± 0.2 dB
MS272xB Reading
dBm –50 dBm ± 0.2 dB
Calculated Channel
Power Error
dB ±1.5 dB
Table A-150.Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –15.0 dBm) Option 66
Measured Value Specification
Power Meter Reading
dBm –15 dBm ± 0.2 dB
MS272xB Reading
dBm –15 dBm ± 0.2 dB
Calculated Channel
Power Error
dB ±1.5 dB
Table A-151.Mobile WiMAX Channel Power Accuracy Power Error (3600.5 MHz and –50.0 dBm) Option 66
Measured Value Specification
Power Meter Reading
dBm –50 dBm ± 0.2 dB
MS272xB Reading
dBm –50 dBm ± 0.2 dB
Calculated Channel
Power Error
dB ±1.5 dB
