A-28 PN: 10580-00177 Rev. D MS2721B MM
ISDB-T SFN Analyzer Option 32 Verification (continued)
ISDB-T SFN Analyzer Noise Floor
Option 31 GPS Receiver
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-73. ISDB-T SFN Analyzer Noise Floor Pre Amp OFF, Option 32
Channel Frequency Ref Level Measured Value Specification
13 473.14285714 MHz –25 dBm dBm ≤ –70 dBm
38 623.14285714 MHz –25 dBm dBm ≤ –70 dBm
62 767.14285714 MHz –25 dBm dBm ≤ –70 dBm
Table A-74. ISDB-T SFN Analyzer Noise Floor Pre Amp ON, Option 32
Channel Frequency Ref Level Measured Value Specification
13 473.14285714 MHz –50 dBm dBm ≤ –94 dBm
38 623.14285714 MHz –50 dBm dBm ≤ –94 dBm
62 767.14285714 MHz –50 dBm dBm ≤ –94 dBm
Table A-75. GPS Spectrum Analyzer Frequency Accuracy, Option 31
Test Level Measured Value Error Specification
7GHz GHz Hz
± 4.75 Hz (w/GPS Hi Accy)
or ± 9.5 Hz (W/Int Hi Accy)
