Anritsu Spectrum Master MS2721B Maintenance Manual

A-50 PN: 10580-00177 Rev. D MS2721B MM
LTE Signal Analyzer Option Verification (Option 541 and Option 542)
LTE Channel Power Accuracy (Option 541)
LTE Residual EVM and Frequency Accuracy (Option 542)
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-156.LTE Channel Power Accuracy (Only for Instruments with Option 541 Installed)
Frequency Input Power Measured Channel Power Error Specification
750 MHz –10 dBm dBm dB ± 1.5 dB
750 MHz –50 dBm dBm dB ± 1.5 dB
2150 MHz –10 dBm dBm dB ± 1.5 dB
2150 MHz –50 dBm dBm dB ± 1.5 dB
Table A-157.LTE Residual EVM and Frequency Accuracy (Only for Instruments with Option 542 Installed)
750 MHz at –10 dBm Specification Measured Value
Frequency Error
±10Hz Hz
EVM (rms)
<2.5% %
Table A-158.LTE Residual EVM and Frequency Accuracy (Only for Instruments with Option 542 Installed)
750 MHz at –50 dBm Specification Measured Value
Frequency Error
±10Hz Hz
EVM (rms)
<2.5% %
Table A-159.LTE Residual EVM and Frequency Accuracy (Only for Instruments with Option 542 Installed)
2150 MHz at –10 dBm Specification Measured Value
Frequency Error
±10Hz Hz
EVM (rms)
<2.5% %
Table A-160.LTE Residual EVM and Frequency Accuracy (Only for Instruments with Option 542 Installed)
2150 MHz at –50 dBm Specification Measured Value
Frequency Error
±10Hz Hz
EVM (rms)
<2.5% %
