Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-15
ISDB-T Signal Analyzer Option 30 Verification
Frequency Accuracy and Residual MER Verification
Frequency Lock Range Verification
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-43. ISDB-T Signal Analyzer Frequency Accuracy, Option 30
Channel Frequency
Ref
Level
Pre Amp Off
Freq Error Spec.
Ref
Level
Pre Amp On
Freq Error Spec.
13 473.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
38 623.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
62 767.14285714 MHz –20 dBm Hz ± 0.3 Hz –50 dBm Hz ± 0.3 Hz
Table A-44. ISDB-T Signal Analyzer Residual MER, Option 30
Channel Frequency Total MER Pre Amp Off Spec. Total MER Pre Amp On Spec.
13 473.14285714 MHz dB ≥ 42 dB dB ≥ 37 dB
38 623.14285714 MHz dB ≥ 42 dB dB ≥ 37 dB
62 767.14285714 MHz dB ≥ 42 dB dB ≥ 37 dB
Table A-45. ISDB-T Signal Analyzer Frequency Lock Range, Option 30
Channel Frequency Measured Frequency Error Specification
13 473.14285714 MHz Hz ± 0.3 Hz
13 473.14285714 MHz Hz ± 0.3 Hz
