Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-49
Mobile WiMAX Demodulator Option 67
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-152.Mobile WiMAX Residual EVM (10 MHz Bandwidth and 10 ms Frame Length), Option 67
Frequency Power BW EVM (RMS) Specification
2600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
2600.5 MHz –50 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –15 dBm 10 MHz % ≤ 3.0%
3600.5 MHz –50 dBm 10 MHz % ≤ 3.0%
Table A-153.Mobile WiMAX Residual EVM (5 MHz Bandwidth and 5 ms Frame Length), Option 67
Frequency Power BW EVM (RMS) Specification
2600.5MHz –15dBm 5MHz % ≤ 3.0%
2600.5MHz –50dBm 5MHz % ≤ 3.0%
3600.5MHz –15dBm 5MHz % ≤ 3.0%
3600.5MHz –50dBm 5MHz % ≤ 3.0%
Table A-154.Mobile WiMAX Frequency Error (10 MHz Bandwidth and 10 ms Frame Length), Option 67
Frequency Power Frequency Error Specification
2600.5MHz –50dBm Hz ±10Hz
3600.5MHz –50dBm Hz ±10Hz
Table A-155.Mobile WiMAX Frequency Error (5 MHz Bandwidth and 5 ms Frame Length), Option 67
Frequency Power Frequency Error Specification
2600.5MHz –50dBm Hz ±10Hz
3600.5MHz –50dBm Hz ±10Hz
