DVB-T/H SFN Analyzer Option 78 Verification
DVB-T/H SFN Level Accuracy Verification (Option 78)
DVB-T/H SFN Level Level Accuracy Verification (Option 78)
DVB-T/H SFN Level 1 dB Compression Level Verification (Option 78)
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-161.Readings for Sensor A, Sensor B, DAB(–10), and MN63A Attenuation AT(–10), Option 78
Frequency
(Channel) Sensor A Reading Sensor B Reading DAB(–10)
MN63A Attenuation
Reading, AT(–10)
474 MHz (Ch 21)
666 MHz (Ch 45)
858 MHz (Ch 69)
Table A-162.Readings for Sensor A, Sensor B, DAB(–50), and MN63A Attenuation AT(–50), Option 78
Frequency
(Channel) Sensor A Reading Sensor B Reading DAB(–50)
MN63A Attenuation
Reading, AT(–50)
474 MHz (Ch 21)
666 MHz (Ch 45)
858 MHz (Ch 69)
Table A-163.Readings for Sensor A and MN63A Attenuation AT(–25), AT(–15), AT(–50), and AT(–43), Option 78
Frequency
(Channel)
Sensor A
Reading,
M(Sa)
MN63A
Attenuation
Reading,
AT(– 25)
MN63A
Attenuation
Reading,
AT(– 15)
MN63A
Attenuation
Reading,
AT(– 50)
MN63A
Attenuation
Reading,
AT(–43)
474 MHz (Ch 21)
666 MHz (Ch 45)
858 MHz (Ch 69)
