Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-11
Amplitude Accuracy Across Frequency Verification (continued)
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-29. Amplitude Accuracy Across Frequency Verification at 4000 MHz
Input Power Attenuation Level Marker 1 Reading Specification
–30dBm 0dB dBm ±1.25dB
–30dBm 5dB dBm ±1.25dB
–30 dBm 10 dB dBm ± 1.25 dB
–30 dBm 20 dB dBm ± 1.25 dB
–2dBm 30dB dBm ±1.25dB
–2dBm 40dB dBm ±1.75dB
–2dBm 50dB dBm ±1.75dB
–2dBm 60dB dBm ±1.75dB
Table A-30. Amplitude Accuracy Across Frequency Verification at 5000 MHz
Input Power Attenuation Level Marker 1 Reading Specification
–30dBm 0dB dBm ±1.75dB
–30dBm 5dB dBm ±1.75dB
–30 dBm 10 dB dBm ± 1.75 dB
–30 dBm 20 dB dBm ± 1.75 dB
–2dBm 30dB dBm ±1.75dB
–2dBm 40dB dBm ±1.75dB
–2dBm 50dB dBm ±1.75dB
–2dBm 60dB dBm ±1.75dB
Table A-31. Amplitude Accuracy Across Frequency Verification at 6000 MHz
Input Power Attenuation Level Marker 1 Reading Specification
–30dBm 0dB dBm ±1.75dB
–30dBm 5dB dBm ±1.75dB
–30 dBm 10 dB dBm ± 1.75 dB
–30 dBm 20 dB dBm ± 1.75 dB
–2dBm 30dB dBm ±1.75dB
–2dBm 40dB dBm ±1.75dB
–2dBm 50dB dBm ±1.75dB
–2dBm 60dB dBm ±1.75dB
