Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-5
Spectrum Analyzer Residual Spurious
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-10. Spectrum Analyzer Residual Spurious (Pre Amp On)
Start Frequency Stop Frequency Measured Value Specification
100 kHz 10 MHz dBm ≤ –100 dBm
10 MHz 1 GHz dBm ≤ –100 dBm
1GHz 2GHz dBm ≤ –100 dBm
2GHz 3GHz dBm ≤ –100 dBm
3GHz 4GHz dBm ≤ –100 dBm
4GHz 5GHz dBm ≤ –100 dBm
5GHz 6GHz dBm ≤ –100 dBm
6GHz 7.1GHz dBm ≤ –100 dBm
Table A-11. Spectrum Analyzer Residual Spurious (Pre Amp Off)
Start
Frequency
Stop
Frequency RBW VBW Marker 1 Reading Specification
100 kHz 10 MHz 3 kHz 300 Hz dBm ≤ –90 dBm
10MHz 1.0GHz 30kHz 1kHz dBm ≤ –90 dBm
1.0 GHz 2.2 GHz 10 kHz 300 Hz dBm ≤ –90 dBm
2.2 GHz 2.7 GHz 1 kHz 300 Hz dBm ≤ –90 dBm
2.7 GHz 2.8 GHz 1 kHz 100 Hz dBm ≤ –90 dBm
2.8 GHz 3.199 GHz 10 kHz 300 Hz dBm ≤ –90 dBm
3.2 GHz 4.009 GHz 30 kHz 1 kHz dBm ≤ –84 dBm
4.009 GHz 5.083 GHz 10 kHz 300 Hz dBm ≤ –84 dBm
5.083 GHz 5.895 GHz 10 kHz 100 Hz dBm ≤ –84 dBm
5.895 GHz 7.1 GHz 10 kHz 100 Hz dBm ≤ –84 dBm
Table A-12. Spectrum Analyzer Residual Spurious (Pre Amp Off) – Exceptions
Exceptions Frequency Spur Level
250MHz, 300MHz, and 250MHz ≤ –85 dBm max.
~ 4010 MHz ≤ –80 dBm max.
~ 5084 MHz ≤ –70 dBm max.
~ 5894 MHz ≤ –75 dBm max.
~ 7028 MHz ≤ –80 dBm max.
