Anritsu Spectrum Master MS2721B Maintenance Manual

A-40 PN: 10580-00177 Rev. D MS2721B MM
Option 64 DVB-T/H Signal Analyzer
DVB-T/H Signal Analyzer Frequency Accuracy
DVB-T/H Signal Analyzer Residual MER
DVB-T/H Signal Analyzer Frequency Lock Range
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-125.DVB-T/H Signal Analyzer Frequency Accuracy for –20 dBm Reference Level, Option 64
Channel Reference Level Frequency Error Specification
21 –20 dBm Hz ± .03 Hz
45 –20 dBm Hz ± .03 Hz
69 –20 dBm Hz ± .03 Hz
Table A-126.DVB-T/H Signal Analyzer Frequency Accuracy for –50 dBm Reference Level, Option 64
Channel Reference Level Frequency Error Specification
21 –50 dBm Hz ± .03 Hz
45 –50 dBm Hz ± .03 Hz
69 –50 dBm Hz ± .03 Hz
Table A-127.DVB-T/H Signal Analyzer Residual MER Pre Amp OFF, Option 64
Channel Total MER Specification
21 dB ≥ 42 dB
45 dB ≥ 42 dB
69 dB ≥ 42 dB
Table A-128.DVB-T/H Signal Analyzer Residual MER Pre Amp ON, Option 64
Channel Total MER Specification
21 dB ≥ 37 dB
45 dB ≥ 37 dB
69 dB ≥ 37 dB
Table A-129.DVB-T/H Signal Analyzer Frequency Lock Range, Option 64
Channel Frequency Measured Frequency Error Specification
21 474.09 MHz Hz ± 0.3 Hz
21 473.91 MHz Hz ± 0.3 Hz
