General Information 1-2 Recommended Test Equipment
MS2721B MM PN: 10580-00177 Rev. D 1-3
Optional Functions Verification
Table 1-2. Test Equipment Required for Verifying Functions of Installed Options
Instrument Critical Specification Recommended Manufacturer/Model
Synthesizer Frequency: 0.1 Hz to 20 GHz,
+16 dBm power
Anritsu Model MG3692A or MG3692B
with options 2A, 4, 15, and 22
a
Vector Signal Generator Frequency: 100 kHz to 3 GHz Anritsu Model MG3700A with
Options: MG3700A-002, MG3700A-021
b
,
and Waveform Data License MX370001A
and MX370108A
Power Meter Power Range: –70 to +20 dBm Anritsu Model ML2438A
Power Sensor Frequency: 10 MHz to 18 GHz
Power Range: –60 to +20 dBm
Anritsu Model MA2482D with Option 1
(Qty 2)
Frequency Counter Frequency: 20 GHz Anritsu Model MF2412B
Frequency Reference Frequency: 10 MHz Symmetricom RubiSource T&M
Programmable Attenuator Frequency: DC to 2 GHz
Attenuation:100 dB
(1 dB and 10 dB steps)
Anritsu Model MN63A
Fixed Attenuator Frequency Range:
DC to 18 GHz
Attenuation: 10 dB
Aeroflex/Weinschel Model 44-10 (Qty 2)
Power Splitter Frequency: DC to 18 GHz Aeroflex/Weinschel Model 1870A
RF Power Amplifier Frequency: 100 to 1000 MHz
Gain: 35 dB min.
Mini Circuits Model TIA-1000-1R8 (Qty 2
BNC(m)-N(f) Adapters required)
Adapter Frequency: DC to 20 GHz
N(m)-N(m), 50 Ohm
Maury Microwave Model 8828B
Quantity: 2 each [One each required only
if Anritsu Coupler and Circulator are used]
Adapter Frequency: DC to 20 GHz
K(m)-N(f), 50 Ohm
Anritsu Model 34RKNF50
Adapter Frequency: DC to 20 GHz
K(m)-N(f), 50 Ohm
Anritsu Model 34NN50A
Adapter Frequency: 881.5 MHz
BNC(m)-N(f), 50 Ohm
Midwest Microwave Model
ADT-2615-NF-BNM-02 (Qty 2)
Adapter Frequency: 881.5 MHz
SMA(m)-to-N(f), 50 Ohm
Midwest Microwave Model
ADT-2582-NF-SMM-02 (Qty 4) [Required
only if Anritsu Coupler and Circulator are
used.]
Adapter Frequency: 881.5 MHz
SMA(m)-SMA(m), 50 Ohm
Midwest Microwave Model
ADT-2594-MM-SMA-02 [Required only if
Anritsu Coupler and Circulator are used.]
50 Ohm Termination Frequency: DC to 18 GHz Anritsu Model 28N50-2
RF Limiter Frequency: 10 MHz to 18 GHz
N(m) In, N(f) Out, 50 ohm
Anritsu Model 1N50C
High Power Load DC to 18 GHz, 10 W Aeroflex/Weinschel Model M1418
