Anritsu Spectrum Master MS2721B Maintenance Manual

MS2721B MM PN: 10580-00177 Rev. D A-37
Option 60 or Option 61 TD-SCDMA Signal Analyzer Option Verification
Option 62 EVDO RF Measurements
MS2721B Firmware Revision: ________________ Operator: ________________ Date: ______________
Serial Number: ________________ Options: ___________________________________________________
Table A-114.TD-SCDMA (at 2010 MHz, –45 dBm Level) (Option 60 or Option 61)
Measurement Type Measured Value Specification
Power Meter Reading
dBm –45 dBm ± 0.5 dB
Displayed Channel Power
dBm –45 dBm ± 0.5 dB
Channel Power Error
dB ± 1.0 dB
EVM
%<3%
Frequency Error
Hz ± 20 Hz
Tau
µs ± 0.1 µs
Table A-115.EVDO Channel Power Error at 870.03 MHz, –50 dBm Level, 921.6 kps 8-PSK Modulation, Option 62
Measurement Type Measured Value Specification
Power Meter Reading
dBm –50 dBm ± 0.2 dB
MS2721B Power Reading
dBm –50 dBm ± 0.2 dB
Calculated
Channel Power Error
dB ± 1.0 dB
Table A-116.EVDO Channel Power Error at 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation, Option 62
Measurement Type Measured Value Specification
Power Meter Reading
dBm 0 dBm ± 0.2 dB
MS2721B Power Reading
dBm 0 dBm ± 0.2 dB
Calculated
Channel Power Error
dB ± 1.0 dB
