Performance Verification 2 3-6 ISDB-T SFN Analyzer (Option 32) Verification
MS2721B MM PN: 10580-00177 Rev. D 3-25
Figure 3-9. Level Accuracy and 1 dB Compression Level Pretest Setup – Two Sensors
Function
Ethernet Control Input Modulation Input
Cursor/Edit
RF Output
3
MG3700
Vector Signal
Generator
250kHz-6GHz
3
Mini-Circuits
RF POWER AMPLIFIER
MODEL TIA - 1000 - 1R8
INPUT
OUTPUT
ON
OFF
TEMP
AC
0.5 - 100 MHz 35dB GAIN
4 WATTS SATURATED
1.8 WATTS LINEAR
Sensor A
Sensor B
MS2721B
MG3700A
ML2438A Power Meter
1870A
IN50C
RF POWER AMPLIFIER
34NN50A
MN63A
15NN50-1.5C
15NN50-1.5C
