Anybus CompactCom 40 User Manual

Host Application Objects 160 (258)
Attr ID#
Access
Rule Name
Data Type
Element
number:description
PROFIenergy
Measurement ID
5
Get Min VoltagePH-
PH
UINT64
FLOAT
UINT32
0: L1-L2 TS
1: L1-L2 Value
2: Reserved
73
UINT64
FLOAT
UINT32
3: L2-L3 TS
4: L2-L3 Value
5: Reserved
74
UINT64
FLOAT
UINT32
6: L3-L1 TS
7: L3-L1 Value
8: Reserved
75
UINT64
FLOAT
UINT32
9: Avg L-L TS
10: Avg L-L Value
11: Reserved
93
6 Get Max VoltagePH-
PH
UINT64
FLOAT
UINT32
0: L1-L2 TS
1: L1-L2 Value
2: Reserved
43
UINT64
FLOAT
UINT32
3: L2-L3 TS
4: L2-L3 Value
5: Reserved
44
UINT64
FLOAT
UINT32
6: L3-L1 TS
7: L3-L1 Value
8: Reserved
45
UINT64
FLOAT
UINT32
9: Avg L-L TS
10: Avg L-L Value
11: Reserved
63
7
Get Voltage PH-G UINT64
FLOAT
UINT32
0: L1-G TS
1: L1-G Value
2: Reserved
-
UINT64
FLOAT
UINT32
3: L2-G TS
4: L2-G Value
5: Reserved
UINT64
FLOAT
UINT32
6: L3-G TS
7: L3-G Value
8: Reserved
UINT64
FLOAT
UINT32
9: Avg L-G TS
10: Avg L-G Value
11: Reserved
8 Get Min VoltagePH-
G
UINT64
FLOAT
UINT32
0: L1-G TS
1: L1-G Value
2: Reserved
-
UINT64
FLOAT
UINT32
3: L2-G TS
4: L2-G Value
5: Reserved
UINT64
FLOAT
UINT32
6: L3-G TS
7: L3-G Value
8: Reserved
UINT64
FLOAT
UINT32
9: Avg L-G TS
10: Avg L-G Value
11: Reserved
9 Get Max VoltagePH-
G
UINT64
FLOAT
UINT32
0: L1-G TS
1: L1-G Value
2: Reserved
-
UINT64
FLOAT
UINT32
3: L2-G TS
4: L2-G Value
5: Reserved
UINT64
FLOAT
UINT32
6: L3-G TS
7: L3-G Value
8: Reserved
UINT64
FLOAT
UINT32
9: Avg L-G TS
10: Avg L-G Value
11: Reserved
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
