Anybus CompactCom 40 User Manual

Host Application Objects 161 (258)
Attr ID#
Access
Rule Name
Data Type
Element
number:description
PROFIenergy
Measurement ID
10 Get Current UINT64
FLOAT
UINT32
0: L1 TS
1: L1 Value
2: Reserved
7
UINT64
FLOAT
UINT32
3: L2 TS
4: L2 Value
5: Reserved
8
UINT64
FLOAT
UINT32
6: L3 TS
7: L3 Value
8: Reserved
9
UINT64
FLOAT
UINT32
9: Avg L TS
10: Avg L Value
11: Reserved
33
UINT64
FLOAT
UINT32
12: N TS
13: N Value
14: Reserved
-
11 Get Min Current UINT64
FLOAT
UINT32
0: L1 TS
1: L1 Value
2: Reserved
76
UINT64
FLOAT
UINT32
3: L2 TS
4: L2 Value
5: Reserved
77
UINT64
FLOAT
UINT32
6: L3 TS
7: L3 Value
8: Reserved
78
UINT64
FLOAT
UINT32
9: Avg L TS
10: Avg L Value
11: Reserved
94
UINT64
FLOAT
UINT32
12: N TS
13: N Value
14: Reserved
-
12 Get Max Current UINT64
FLOAT
UINT32
0: L1 TS
1: L1 Value
2: Reserved
46
UINT64
FLOAT
UINT32
3: L2 TS
4: L2 Value
5: Reserved
47
UINT64
FLOAT
UINT32
6: L3 TS
7: L3 Value
8: Reserved
48
UINT64
FLOAT
UINT32
9: Avg L TS
10: Avg L Value
11: Reserved
64
UINT64
FLOAT
UINT32
12: N TS
13: N Value
14: Reserved
-
13 Get Apparent Power UINT64
FLOAT
UINT32
0: L1 TS
1: L1 Value
2: Reserved
10
UINT64
FLOAT
UINT32
3: L2 TS
4: L2 Value
5: Reserved
11
UINT64
FLOAT
UINT32
6: L3 TS
7: L3 Value
8: Reserved
12
UINT64
FLOAT
UINT32
9: Total TS
10: Total Value
11: Reserved
36
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
