Anybus CompactCom 40 User Manual

Host Application Objects 179 (258)
Supported Commands
Object: Get_Attribute
StartPause
EndPause
Preview_Pause_Time (not PROFINET)
Instance: Get_Attribute
Object Attributes (Instance #0)
# Name Access Data Type Value
1 Name Get Array of
CHAR
“Energy Control”
2 Revision Get UINT8 02h
3 Number of instances Get UINT16
-
4 Highest instance no. Get UINT16 Highest created instance number. Maximum value is 8.
11 Current Energy Sav-
ing Mode
Get UINT16 Instance number of the currently used Energy saving mode.
During a mode transition the new Energy saving mode shall be
presented. “Ready to operate” will equal instance #1, and
“Power off” mode will equal Highest instance number.
12 Remaining time to
destination
Get UINT32 When changing mode this parameter will reflect the actual time
(in milliseconds) remaining until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is infinite, or unknown, the maximum value
0xFFFFFFFF shall be used.
13 Energy consumption
to destination
Get FLOAT When changing mode this parameter will reflect the actual en-
ergy (in kWh) which will be consumed until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is undefined the value 0.0 shall be used.
14 Transition to “Power
off” mode supported
Get BOOL Indicates whether transition to “Power off” mode is supported or
not.
0: Not supported
1: Supported
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
