Appendix F: AIDA LED Mode 221 (258)
F.2.2 Bus Failure LED
LED State Description Comments
Off Ok No problem
Red Fatal event Major internal error (this indication is combined with a red sys-
tem failure LED)
Station Name error Station Name not set
IP address error IP address not set
Configuration error Expected Identification differs from Real Identification
Online (STOP) Connection with IO Controller established
• IO Controller in STOP state or IO data BAD
• IRT synchronization not finished
F.2.3 System Failure LED
LED State Description Comments
Off Not Initialized No problems detected
Red Exception error Device in state EXCEPTION.
FATAL event Major internal error (this indication is combined with a red bus
failure LED)
Diagnostic Event(s) Diagnostic event(s) present
F.2.4 Port Link LED
LED State Description Comments
Off No Link No link, no communication present
Green Link Ethernet link established
Green, blinking DCP Identify Used by engineering tools to identify the node on the network
500 ms on, 500 ms off during 3 seconds
The signal is also available in the host application connector:
AIDA indication Signal Name, Application Interface Connector
Link on port 1 LED3A
Link on port 2 LED4A
The Port Link signals are always available in the host application connector in all operating
modes except 16 bit parallel. For more information consult the Anybus CompactCom M40 Hard-
ware Design Guide (module) or the Anybus CompactCom B40-1 Design Guide (brick).
When Transparent Ethernet is activated, the LED status signals are only available in the LED
status register.
F.2.5 Port Activity Indication
AIDA LED State Description
Off No Activity
Orange, flashing Activity
There is no LED on the front of the Anybus CompactCom 40 PROFINET IRT showing this indi-
cation, but the signal is available in the host application connector according to this table:
AIDA indication Signal Name, Host Application Connector
Activity on port 1 LED3B
Activity on port 2 LED4B
