Page #245 background image
Appendix H: Backward Compatibility 243 (258)
Module Status LED (LED2[A..B])
LED State 30-series 40-series Comments
Off Not Initialized Not Initialized No power or Module in SETUP or
NW_INIT state
Green Normal Operation Normal Operation Module has shifted from the NW_IN-
IT state
Green, 1 flash Diagnostic Event Diagnostic Event Diagnostic event(s) present
Green, cont. flash Identify
-
Flashing 1Hz continuously to identify
slave (DCP_Identify).
Red Exception error Exception error Module in state Exception
Fatal Event Fatal Event Major internal error (this indication is
combined with a red Network Status
LED)
Red, 1 flash Configuration error
-
Red, 2 flashes IP address error
-
Red, 3 flashes Station Name Error
-
Red, 4 flashes Internal error
-
Alternating Red/
Green
-
Firmware Update Do NOT power off the module. Turn-
ing the module off during this phase
could cause permanent damage.
H.4.9 SNMP MIB-II
sysContact, sysLocation and sysName are used to give the product identification in the end
installation.
In the 40-module these variables are only set from the network using SNMP protocol by the end
user.
Due to this, sysContact (PROFINET IO object (F6h), Attribute 22), sysLocation (Network Con-
figuration Object (04h), Attribute 17) and sysName (Network Configuration Object (04h), Attrib-
ute 15) are no longer used.
Nothing needs to be updated in your implementation but attribute values will no longer be used.
Anybus
®
CompactCom
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
