7.2.2 Ethernet Statistics Page
The Ethernet statistics web page contains the following information:
Current IP Configuration Description
DHCP:
-
Host Name:
-
IP Address:
-
Subnet Mask:
-
Gateway Address:
-
DNS Server #1:
-
DNS Server #2:
-
Domain Name:
-
Current Ethernet Configuration Description
MAC Address
-
Port 1 Speed: The current link speed.
Duplex: The current duplex configuration.
Port 2 Speed: The current link speed.
Duplex: The current duplex configuration.
Interface Counters Description
In Octets: Received bytes.
In Ucast Packets: Received unicast packets.
In NUcast packets: Received non-unicast packets (broadcast and multicast).
In Discards: Received packets discarded due to no available memory buffers.
In Errors: Received packets discarded due to reception error.
In Unknown Protos: Received packets with unsupported protocol type.
Out Octets: Sent bytes.
Out Ucast packets: Sent unicast packets.
Out NUcast packets: Sent non-unicast packets (broadcast and multicast).
Out Discards: Outgoing packets discarded due to no available memory buffers.
Out Errors: Transmission errors.
Media Counters Description
Alignment Errors Frames received that are not an integral number of octets in length.
FCS Errors Frames received that do not pass the FCS check.
Single Collisions Successfully transmitted frames which experienced only one collision.
Multiple Collisions Successfully transmitted frames that experienced more than one
collision.
SQE Test Errors Number of times SQE test error messages are generated.
Deferred Transmissions Frames for which first transmission attempt is delayed because the
medium is busy.
Late Collisions Number of times a collision is detected later than 512 bit-times into
the transmission of a packet.
Excessive Collisions Frames for which a transmission fails due to excessive collisions.
MAC Receive Errors Frames for which reception of an interface fails due to an internal
MAC sublayer receive error.
MAC Transmit Errors Frames for which transmission fails due to an internal MAC sublayer
receive error.
Carrier Sense Errors Times that the carrier sense condition was lost or never asserted
when attempted to transmit a frame.
Frame Size Too Long Frames received that exceed the maximum permitted frame size.
Frame Size Too Short Frames received that are shorter than lowest permitted frame size.
