Anybus CompactCom 40 User Manual

JSON 78 (258)
mediacounters.json
GET network/mediacounters.json?port=<port>
The argument <port> is either 1 or 2.
Port number 2 option is only valid if two Ethernet ports are activated in the module.
Name Data Type Description
align Number Frames received that are not an integral number of octets
in length
fcs Number Frames received that do not pass the FCS check
singlecoll Number Successfully transmitted frames which experienced ex-
actly one collision
multicoll Number Successfully transmitted frames which experienced more
than one collision
latecoll Number Number of collisions detected later than 512 bit times into
the transmission of a packet
excesscoll Number Frames for which transmissions fail due to excessive
collisions
sqetest Number Number of times SQE test error is generated
deferredtrans Number Frames for which the first transmission attempt is delayed
because the medium is busy
macrecerr
Number Frames for which reception fails due to an internal MAC
sublayer receive error
mactranserr Number Frames for which transmission fails due to an internal
MAC sublayer transmit error
cserr
Number Times that the carrier sense was lost or never asserted
when attempting to transmit a frame
toolong Number Frames received that exceed the maximum permitted
frame size
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
